Hyundai R215L-7 Excavator

A robust 22-tonne long-undercarriage crawler excavator powered by the Cummins 6BTAA-5.9C engine with 148 HP gross output, 2×220 L/min dual-pump hydraulics with cross-sensing control, Hi-Track remote management system, and a strengthened undercarriage delivering 21,100 kgf of drawbar pull at a 35° gradeability.

Engine icon
Engine Power148 HP @ 2,000 RPM
Bucket icon
Bucket Capacity1.05 m³ (std GP)
Weight icon
Operating Weight22,200 Kg
Digging depth icon
Max Digging Depth6,220 mm
Dumping height icon
Max Dumping Height6,490 mm
Reach icon
Max Reach (Ground)9,309 mm
Download Brochure
Enter email to get the brochure

Key Highlights

Engine model icon
Engine Model

Cummins 6BTAA-5.9C

Displacement icon
Displacement

5.88 L — 6 Cylinder Inline

Torque icon
Max Torque

625 N-m @ 1,300 RPM

Travel speed icon
Travel Speed

High: 5.3 km/h / Low: 3.4 km/h

Hydraulics icon
Hydraulic System

2 × 220 L/min variable displacement pumps

Digging height icon
Max Digging Height

9,266 mm (2.4 m arm)

Gradeability icon
Gradeability

70% / 35°

Dumping height icon
Max Dumping Height

6,490 mm (2.4 m arm)

Overall length icon
Overall Length

9,610 mm

Track shoe icon
Track Shoe Width

600 mm (standard)

Bucket digging force icon
Bucket Digging Force

155 kN ISO (15,800 kgf)

Arm crowd force icon
Arm Crowd Force

124 kN ISO (12,600 kgf)

Hi-Track icon
Hi-Track Telematics

Standard — GPS + Remote Monitoring

Ground pressure icon
Ground Pressure

46.1 kPa / 0.47 kgf/cm² (600 mm)

Drawbar pull icon
Max Drawbar Pull

21,100 kgf (46,500 lbf)

Specifications

Product specification of Hyundai R215L-7 Excavator

ENGINE

  • Model

    Cummins 6BTAA-5.9C

  • Type

    4-cycle diesel, 6-cylinder inline, water-cooled, turbocharged, charge air cooled, direct injection

  • Gross Power (SAE J1995)

    148 HP (110 kW) @ 2,000 RPM

  • Net Power (SAE J1349)

    145 HP (108 kW) @ 2,000 RPM

  • Max Torque

    625 N-m (63.7 kgf-m / 461 lbf-ft) @ 1,300 RPM

  • No. of Cylinders

    6

  • Displacement

    5,880 cc (5.88 L)

  • Battery

    2 × 12 V / 100 Ah

TRAVEL & SWING

  • Swing Speed: 11 RPM
  • Swing Motor: Axial piston motor with automatic brake
  • Swing Reduction: Planetary gear reduction
  • Swing Bearing Lubrication: Grease bathed
  • Swing Brake: Multi wet disc
  • Travel Speed High: 5.3 km/h
  • Travel Speed Low: 3.4 km/h
  • Max Drawbar Pull: 21,100 kgf (46,500 lbf / 207 kN)
  • Gradeability: 35° (70%)
  • Travel Motor: Two-speed axial piston motor with counter balance valve and parking brake
  • Drive Method: Fully hydrostatic type
  • Reduction System: Planetary reduction gear
  • Parking Brake: Multi wet disc

UNDERCARRIAGE

  • Centre Frame: X-leg type
  • Track Frame: Pentagonal box type
  • Track Shoes (each side): 49
  • Carrier Rollers (each side): 2
  • Track Rollers (each side): 9
  • Rail Guard (each side): 2
  • Standard Track Width: 600 mm (24")
  • Track Gauge: 2,390 mm
  • Tumbler Distance: 3,640 mm
  • Overall Distance of Crawler: 4,440 mm
  • Overall Width (600mm shoe): 2,990 mm
  • Ground Pressure (600mm shoe): 0.47 kgf/cm² (46.1 kPa / 6.68 psi)

RELIEF VALVE

  • Implement Circuit: 330 kgf/cm² (32.4 MPa / 4,700 psi)
  • Travel Circuit: 330 kgf/cm² (32.4 MPa / 4,700 psi)
  • Swing Circuit: 240 kgf/cm² (23.5 MPa / 3,413 psi)
  • Pilot Circuit: 35 kgf/cm² (3.4 MPa / 497 psi)
  • Service Valve: Installed

HYDRAULIC SYSTEM

  • Main Pump Type: 2 variable displacement piston pumps
  • Max Oil Flow: 2 × 220 L/min
  • Pilot Pump: Gear pump (sub-pump)
  • Control System: Cross-sensing & fuel saving pump system
  • Travel Motor: Two-speed axial piston motor with counter balance valve and parking brake
  • Swing Motor: Axial piston motor with automatic brake
  • Operating Modes: 3-power mode, 2-work mode
  • ECO Mode: New ECO mode — reduced fuel consumption
  • Auto Deceleration: One-touch idle & auto deceleration standard
  • Breaker Mode: Exclusive breaker mode standard
  • Arm Regeneration: Standard — prevents cavitation, increases performance & fuel efficiency
  • Swing Priority: Standard
  • Hydraulic Flow Summation: Standard — combined operation efficiency
  • Negative Flow Control: Standard
  • CAPO System: Advanced CAPO system with CMCU

WORKING RANGES

  • Boom: 5,680 mm  |  Standard Arm: 2,400 mm (2,000 mm and 2,920 mm optional)
  • — With 2,400 mm Arm (Standard) —
  • Max Digging Reach: 9,474 mm (31' 1")
  • Max Digging Reach (Ground Level): 9,309 mm (30' 7")
  • Max Digging Depth: 6,220 mm (20' 5")
  • Max Digging Depth (8 ft Level): 6,012 mm (19' 9")
  • Max Vertical Wall Digging Depth: 5,276 mm (17' 4")
  • Max Digging Height: 9,266 mm (30' 5")
  • Max Dumping Height: 6,490 mm (21' 4")
  • Min Swing Radius: 3,658 mm (12' 0")
  • — With 2,000 mm Arm —
  • Max Digging Reach: 9,099 mm (29' 10")
  • Max Digging Reach (Ground Level): 8,926 mm (29' 3")
  • Max Digging Depth: 5,820 mm (19' 1")
  • Max Digging Depth (8 ft Level): 5,579 mm (18' 4")
  • Max Vertical Wall Digging Depth: 4,879 mm (16' 0")
  • Max Digging Height: 9,050 mm (29' 8")
  • Max Dumping Height: 6,275 mm (20' 7")
  • Min Swing Radius: 3,776 mm (12' 5")
  • — With 2,920 mm Arm —
  • Max Digging Reach: 9,950 mm (32' 8")
  • Max Digging Reach (Ground Level): 9,793 mm (32' 2")
  • Max Digging Depth: 6,740 mm (22' 1")
  • Max Digging Depth (8 ft Level): 6,560 mm (21' 6")
  • Max Vertical Wall Digging Depth: 5,912 mm (19' 5")
  • Max Digging Height: 9,522 mm (31' 3")
  • Max Dumping Height: 6,730 mm (22' 1")
  • Min Swing Radius: 3,673 mm (12' 1")

DIGGING FORCES

  • Bucket Digging Force (ISO): 155 kN (15,800 kgf / 34,900 lbf)
  • Bucket Digging Force (SAE): 134 kN (13,700 kgf / 30,100 lbf)
  • Arm Crowd Force — 2.4 m Arm (ISO): 124 kN (12,600 kgf / 27,700 lbf)
  • Arm Crowd Force — 2.4 m Arm (SAE): 118 kN (12,000 kgf / 26,500 lbf)
  • Arm Crowd Force — 2.0 m Arm (ISO): 148 kN (15,100 kgf / 33,300 lbf)
  • Arm Crowd Force — 2.0 m Arm (SAE): 140 kN (14,300 kgf / 31,500 lbf)
  • Arm Crowd Force — 2.92 m Arm (ISO): 104 kN (10,600 kgf / 23,300 lbf)
  • Arm Crowd Force — 2.92 m Arm (SAE): 99 kN (10,100 kgf / 22,300 lbf)
  • Standard Working Device: 5,680 mm HD boom, 2,400 mm arm, 3,800 kg counterweight
  • Standard Bucket (Lifting Tables): 1.10 m³ HD — 1,256 mm wide, 1,127 kg, 5 teeth
  • GP Bucket (std arm): 1.05 m³ GP (SAE) / 0.88 m³ (CECE) — 1,132 mm wide, 803 kg, 5 teeth
  • GP Bucket Options: 0.92 m³ (1,032 mm, 738 kg), 1.20 m³ (1,283 mm, 802 kg)
  • HD Bucket Options: 1.10 m³ (1,256 mm, 1,127 kg), 0.95 m³ (1,091 mm, 1,063 kg), 0.87 m³ (966 mm, 982 kg)
  • Coal Bucket: 1.70 m³ SAE — 1,431 mm wide, 908 kg, 5 teeth

WEIGHTS

  • 5,680 mm HD boom, 2,400 mm arm, 1.10 m³ HD bucket, 3,800 kg CWT, 600 mm shoe
  • Operating Weight: 22,200 kg (48,943 lb)
  • Ground Pressure (600mm shoe): 0.47 kgf/cm² (46.1 kPa / 6.68 psi)
  • Overall Width (600mm shoe): 2,990 mm (9' 10")

DIMENSIONS

  • 5,680 mm boom, 2,400 mm arm, 600 mm shoe
  • Overall Length: 9,610 mm (31' 6")
  • Overall Width (600mm shoe): 2,990 mm (9' 10")
  • Overall Height of Cabin: 2,920 mm (9' 7")
  • Overall Height of Boom: 3,210 mm (10' 6")
  • Upper Structure Width: 2,700 mm (8' 10")
  • Track Gauge: 2,390 mm (7' 10")
  • Tail Swing Radius: 2,845 mm (9' 4")
  • Ground Clearance of Counterweight: 1,060 mm (3' 6")
  • Min Ground Clearance: 480 mm (1' 7")
  • Distance Between Tumblers: 3,640 mm (11' 11")
  • Overall Distance of Crawler: 4,440 mm (14' 7")
  • Track Shoe Width: 600 mm (24")

SERVICE CAPACITIES

  • Fuel Tank: 340 L (89.8 gal)
  • Engine Oil: 21 L (5.5 gal)
  • Engine Coolant: 35 L (9.2 gal)
  • Swing Device: 5 L (1.3 gal)
  • Final Drive (each side): 6.0 L (1.6 gal)
  • Hydraulic System (total): 280 L (73.9 gal)
  • Hydraulic Tank: 150 L (39.6 gal)

Popular Comparisons with Hyundai R215L-7

Products

Related Excavators

Frequently Asked Questions

Everything you need to know about the Hyundai R215L-7 Excavator

The Hyundai R215L-7 excavator price in India typically ranges between ₹60 – 80 lakhs (ex-showroom). Prices vary by dealer, region, configuration and optional attachments. Contact your local HD Hyundai Construction Equipment dealer for the most current pricing and financing options.

The Hyundai R215L-7 has an operating weight of 22,200 kg (48,943 lb) in standard configuration with a 5,680 mm HD boom, 2,400 mm arm, 1.10 m³ HD bucket, 3,800 kg counterweight and 600 mm track shoes. Ground pressure is 0.47 kgf/cm² (46.1 kPa).

The R215L-7 is powered by the Cummins 6BTAA-5.9C — a 6-cylinder inline, 5.88 L, water-cooled, turbocharged and charge air cooled diesel engine. Gross power is 148 HP (110 kW) @ 2,000 RPM with maximum torque of 625 N-m @ 1,300 RPM.

With the standard 2,400 mm arm, the R215L-7 achieves a maximum digging depth of 6,220 mm (20' 5") and a maximum ground-level reach of 9,309 mm. With the optional 2,920 mm arm, digging depth increases to 6,740 mm (22' 1") and reach extends to 9,793 mm.

Hi-Track is Hyundai's Remote Management System fitted as standard on the R215L-7. It provides:
  • Fleet Monitoring: Real-time machine operating data accessible via website or mobile app
  • Proactive Maintenance: Service history, schedule reminders and maintenance alerts
  • Security & Geo-fencing: GPS-based geo-fence alerts if the machine moves outside defined boundaries
  • Alarm Notifications: Instant alerts for system faults and critical errors
  • Productivity Reports: Operating time, idle time, travel and breaker use duration comparison

The R215L-7 uses two variable displacement piston pumps delivering 2×220 L/min, supported by a gear sub-pump for the pilot circuit. The system features cross-sensing and a fuel saving pump system, along with an advanced CAPO system with CMCU, arm regeneration, swing priority, hydraulic flow summation and negative flow control. The machine offers 3-power modes, 2-work modes, ECO mode, and an exclusive breaker mode for attachment operations.
