Zoomlion LH650-50 Luffing Jib Tower Crane front view
ZOOMLION Luffing Jib Tower Crane

Zoomlion LH650-50 Luffing Jib Tower Crane

A high-capacity 50-tonne luffing jib tower crane with a 60 m maximum jib, 9.57 T tip load, and 63.05 m free-standing height. Powered by a 650 HP motor and equipped with Zoomlion's R-generation intelligent electric control system featuring zero-speed hover, face recognition, anti-collision, anti-typhoon, and hook visualisation — built for high-rise and confined urban construction.

Max Capacity icon
Max Capacity50 Tonnes
Max Jib Length icon
Max Jib Length60 m
Tip Load icon
Tip Load9.57 T
Free-standing Ht. icon
Free-standing Ht.63.05 m
Motor Power icon
Motor Power650 HP
Design Life icon
Design Life30 Years
Download Brochure
Enter email to get the brochure

Key Highlights

Capacity icon
Max Hoisting Capacity

50 T

Jib icon
Max Jib Length

60 m

Tip load icon
Max Tip Load

9.57 T

Height icon
Free-standing Height

63.05 m

Motor icon
Motor Power

650 HP

Control icon
Control System

R-Generation Intelligent

Hover icon
Zero-speed Hover

Load-matched Lifting

Safety icon
Anti-typhoon

Multi-layer Safety System

Face recognition icon
Face Recognition

Smart Operator Auth

Design life icon
Design Life

30 Years

Specifications

Detailed technical specifications for Zoomlion LH650-50 Luffing Jib Tower Crane

LIFTING CAPACITY

  • Max. Hoisting Capacity50 T
  • Max. Tip Load (at 60 m)9.57 T
  • Crane TypeLuffing Jib Tower Crane (LH Series)

JIB & HEIGHT

  • Max. Jib Length60 m
  • Max. Free-standing Height63.05 m
  • Jib TypeLuffing Jib — ideal for high-density urban sites with limited swing radius

MOTOR & POWER

  • Motor Power650 HP
  • Hoist FunctionLoad-matched lifting — speed adapts to load weight for efficiency
  • SlewingRotary closed-loop de-swirl control for precision load placement

CONTROL SYSTEM

  • SystemR-Generation Intelligent Electric Control System
  • Zero-speed HoverSmooth load hold at any height during placement
  • Load-matched LiftingAutomatic speed optimisation based on load weight
  • Inching ControlPrecise micro-movements for accurate load placement
  • Remote UpgradeRemote firmware update for controller and display screen
  • Remote Wind IndicatorReal-time wind speed monitoring for safe operation
  • Hook VisualisationCamera system for enhanced hook and load visibility
  • Face RecognitionSmart operator authentication for authorised access only

SAFETY SYSTEMS

  • Anti-overloadPrevents lifting beyond rated capacity
  • Anti-collisionAutomatic detection and avoidance of crane-to-crane conflicts
  • Anti-unloadingDetects sudden load release and prevents hazardous rebound
  • Anti-typhoonAutomatic storm securing mode for extreme weather conditions
  • Anchor Item DetectionFoolproof anchor status monitoring before operation

STRUCTURAL & TRANSPORT

  • Design Life30 Years equivalent service life design
  • Mast SectionRound tenon mast section — improved connection strength
  • CabinIntegrated cabin design for operator comfort and ergonomics
  • Surface TreatmentElectrophoresis coating for enhanced corrosion resistance
  • Optional FeaturesCollector ring, Wireless remote control

Popular Comparisons with LH650-50

Products

Related Cranes

Frequently Asked Questions

Everything you need to know about the Zoomlion LH650-50 Luffing Jib Tower Crane

The Zoomlion LH650-50 has a maximum hoisting capacity of 50 Tonnes. At the maximum jib length of 60 m, the tip load is 9.57 T. The crane is powered by a 650 HP motor and is designed for demanding high-rise and infrastructure lifting operations.

The LH650-50 has a maximum luffing jib length of 60 m and a maximum free-standing height of 63.05 m. Its luffing jib design allows operation in confined urban sites where a conventional horizontal jib crane would overlap with adjacent structures.

The LH650-50 features Zoomlion's R-generation intelligent electric control system with load-matched lifting speed, zero-speed hover for smooth load placement, rotary inching for precision, anti-collision and anti-overload protection, remote firmware upgrades, real-time wind indication, hook visualisation cameras, and face recognition for authorised operator access.

The LH650-50 includes anti-overload, anti-collision, anti-unloading, and anti-typhoon protection systems. It also features anchor item detection with foolproof monitoring to ensure the crane is properly anchored before operation begins. These multi-layer safety systems are managed by the R-generation electric control system.

The LH650-50 uses round tenon mast sections for improved connection strength, an electrophoresis coating for superior corrosion resistance, and an integrated operator cabin for ergonomic comfort. It is designed for a 30-year service life and supports optional collector ring and wireless remote control upgrades.
