Zoomlion WA5610-6A Flat-top Tower Crane front view
ZOOMLION Flat-top Tower Crane

Zoomlion WA5610-6A Flat-top Tower Crane

Part of Zoomlion's WA series, the WA5610-6A is a compact flat-top tower crane with a 6-tonne maximum hoisting capacity, 56 m jib, and 97.2 t·m rated lifting moment. With a 40 m free-standing height, 100 m/min hoist speed, and EN-compliant simplified structure, it is built for efficient, high-rise construction and confined urban jobsites with 30+ years service life design.

Max Capacity icon
Max Capacity6 Tonnes
Max Jib Length icon
Max Jib Length56 m
Lifting Moment icon
Lifting Moment97.2 t·m
Free-standing Ht. icon
Free-standing Ht.40 m
Hoist Speed icon
Hoist Speed100 m/min
Tip Load icon
Tip Load1 T @ 56 m
Download Brochure
Enter email to get the brochure

Key Highlights

Capacity icon
Max Hoisting Capacity

6 T

Moment icon
Rated Lifting Moment

97.2 t·m

Jib icon
Max Jib Length

56 m

Height icon
Free-standing Height

40 m

Tip load icon
Tip Load (at 56 m)

1 T

Working load icon
Max Working Load

6 T @ 16.2 m

Hoist speed icon
Max Hoist Speed

100 m/min

Slewing icon
Slewing Speed

0 – 0.8 r/min

Trolley icon
Trolley (Luffing) Speed

0 – 75 m/min

Rope icon
Rope Capacity

440 m

Specifications

Detailed technical specifications for Zoomlion WA5610-6A Flat-top Tower Crane

LIFTING CAPACITY

  • Max. Hoisting Capacity6 T
  • Rated Lifting Moment97.2 t·m
  • Max. Working Range & Load6 T @ 16.2 m radius
  • Tip Load (at Max Jib)1 T @ 56 m

JIB & HEIGHT

  • Max. Jib (Operating Range)56 m
  • Max. Free-standing Height40 m
  • Rope Capacity440 m
  • Crane TypeFlat-top Tower Crane (WA Series)

HOIST & SPEEDS

  • Max. Hoisting Speed100 m/min
  • Trolley (Luffing) Speed0 – 75 m/min
  • Slewing Speed0 – 0.8 r/min

STRUCTURAL

  • Design StandardEN Standards Compliant
  • Service Life Design30+ Years
  • Structural DesignFlat-top (No Top Tower Structure) — Simplified & Modular
  • Approx. Weight~20,000 kg

KEY FEATURES

  • High ConformityEN-compliant design with 30+ years engineered service life
  • Simplified StructureFlat-top design for easy multi-crane working in confined urban sites
  • Operator's CabErgonomic cabin with user-friendly controls and broad visibility
  • AssemblyEfficient assembly and disassembly design — reduced downtime

Popular Comparisons with WA5610-6A

Products

Related Cranes

Frequently Asked Questions

Everything you need to know about the Zoomlion WA5610-6A Flat-top Tower Crane

The Zoomlion WA5610-6A has a maximum hoisting capacity of 6 Tonnes with a rated lifting moment of 97.2 t·m. At its minimum working radius of 16.2 m, it can lift the full 6 T load. At the maximum jib length of 56 m, the tip load is 1 T.

The WA5610-6A has a maximum jib (operating range) of 56 m and a maximum free-standing height of 40 m. The crane's rope capacity is 440 m, supporting extended operations at height.

The WA5610-6A reaches a maximum hoisting speed of 100 m/min for efficient vertical material handling. The trolley (luffing) speed is 0–75 m/min, and the slewing speed is 0–0.8 r/min for smooth, accurate load placement.

The WA5610-6A uses a flat-top (top-slewing) design with no peak or A-frame above the tower head. This simplified structure reduces wind resistance, allows multiple cranes to work in close proximity on dense urban construction sites, and makes assembly and disassembly faster and easier.

The Zoomlion WA5610-6A is compliant with EN (European) standards and is designed for a 30+ year service life. It features an ergonomic operator cabin with user-friendly controls, and an efficient modular assembly design to minimise site setup and teardown time.
