SANY SRC400CR Rough Terrain Crane

A 40-tonne rough terrain crane with 10–31.5 m 4-section U-shape boom and 7.9–13.7 m folding jib (max. height 47.4 m). Powered by Cummins India QSB6.7 CEV BS IV (194 kW / 1,100 N·m), 4×4 drive, 4-mode all-hydraulic steering, 92% gradeability, and SYMC smart control with LMI safety system.

Capacity icon
Capacity40T
Max Boom icon
Max Boom31.5m
Load Moment icon
Load Moment1175 kN·m
Pick & Carry icon
Pick & Carry12.4T
Max Speed icon
Max Speed37 km/h
Fuel Tank icon
Fuel Tank300L
Download Brochure
Enter email to get the brochure

Key Highlights

Lift Capacity icon
Lift Capacity

40T @ 3m radius

Load Moment icon
Load Moment

1,175 kN·m

Boom Range icon
Boom Range

10 – 31.5 m

Fixed Jib icon
Fixed Jib

7.9 m / 13.7 m

Engine icon
Engine

Cummins QSB6.7 / 194 kW

Max Speed icon
Max Speed

37 km/h

Gradeability icon
Gradeability

92% (at stall)

Oper. Weight icon
Oper. Weight

30,600 kg

Counterweight icon
Counterweight

4,000 kg (fixed)

Steering icon
Steering

4-Mode All-Hydraulic

Specifications

Detailed technical specifications for SANY SRC400CR Rough Terrain Crane

ENGINE

  • Engine ModelCummins India QSB6.7
  • Rated Power194 kW @ 2,200 rpm
  • Max. Engine Torque1,100 N·m @ 1,300 rpm
  • Emission StandardCEV BS IV
  • Fuel Tank Capacity300 L
  • Fuel Consumption50 L / 100 km
  • Transmission (India)DANA Automatic
  • Axles (India)MERITOR Heavy Duty
  • Electrical System2 × 12V Maintenance-Free Battery

LIFTING CAPACITY

  • Max. Rated Lifting Capacity40 T @ 3 m radius
  • Max. Load Moment (Basic Boom)1,175 kN·m
  • Max. Load Moment (Full-Extension Boom)755 kN·m
  • Max. Load Moment (Boom + Jib)457 kN·m
  • Max. Lifting Height (Basic Boom)12.9 m
  • Max. Lifting Height (Full Boom)33.9 m
  • Max. Lifting Height (Boom + Jib)47.4 m
  • Max. Working Radius (Boom)28 m
  • Max. Working Radius (Jib)32.5 m
  • Min. Rated Lifting Radius3 m
  • Tail Slewing Radius3.74 m
  • Counterweight4,000 kg (fixed)
  • Gross Weight30,600 kg

BOOM & JIB

  • Boom TypeU-shape, 4 Sections (1 base + 3 telescopic)
  • Boom Length Range10 m – 31.5 m
  • TelescopingSingle Cylinder + Rope Extension Mechanism
  • Jib Type2-Stage Folding Lattice Jib
  • Jib Lengths7.9 m or 13.7 m
  • Jib Offset Angles0°, 15°, 30°
  • Max. Boom + Jib31.5 m + 13.7 m = 45.2 m

HOIST & SWING

  • Main Winch Speed (empty load)0 – 150 m/min (rated: 141 m/min)
  • Aux. Winch Speed (empty load)0 – 150 m/min (rated: 141 m/min)
  • Max. Single Line Pull5 T (main & aux.)
  • Main Hook40T, 4 sheaves, rope rate 8, 320 kg
  • Aux. Hook5T ball hook, 85 kg
  • Main Wire RopeØ16 mm × 165 m
  • Aux. Wire RopeØ16 mm × 135 m
  • Boom Extension / Retraction35 s / 45 s (10–31.5 m)
  • Full Luffing Up / Down34 s / 52 s
  • Slewing Speed0 – 3.2 rpm (360°)

CARRIER & TRAVEL

  • Wheel Formula4 × 4
  • Max. Travel Speed37 km/h
  • Max. Gradeability (at stall)92%
  • Steering ModesIndependent Front / All-Wheel / 4-Wheel Crab / Independent Rear
  • Min. Steering Radius (2W / 4W)11.5 m / 6.2 m
  • Min. Ground Clearance348 mm
  • Outrigger TypeH-Type, 4-Point
  • Outrigger Span (L × T)6.7 m × 6.5 m
  • Tires20.5-25
  • Approach / Departure Angle23° / 20°

DIMENSIONS & WEIGHT

  • Gross Weight30,600 kg
  • Overall Length12,310 mm
  • Overall Width2,625 mm
  • Overall Height3,460 mm
  • Working Temperature-20°C to +46°C

Popular Comparisons with SRC400CR

Products

Related Cranes

Frequently Asked Questions

Everything you need to know about the SANY SRC400CR Rough Terrain Crane

The SANY SRC400CR has a maximum rated lifting capacity of 40 Tonnes with a load moment of 1,175 kN·m. It also supports 12.4 T pick and carry operations, making it versatile for sites where loads need to be moved while suspended.

The SRC400CR features a 4-section telescopic boom ranging from 10 m to 31.5 m. An optional fixed jib of up to 13.7 m can be fitted to extend vertical reach for demanding lifting scenarios.

The SANY SRC400CR is powered by an India Cummins diesel engine, paired with a DANA automatic transmission and MERITOR heavy duty axles — all proven components widely used in Indian construction and off-highway markets for reliable performance.

The SANY SRC400CR supports 4 steering modes, providing exceptional manoeuvrability on confined job sites. Combined with a 37 km/h max speed and 300 L fuel tank, it is designed for efficient transit and all-day operation.

The SANY SRC400CR is equipped with SANY Load Moment Indicator (LMI) with ±3% accuracy, an anemometer for wind speed monitoring, a camera system, GPS tracking, and RootCloud MachineLink+ telematics for real-time remote monitoring and diagnostics.
