SANY STC600S Maintenance Checklist
Daily pre-start checks · Service schedule by operating hours · Warning alert actions — SANY STC600S 60T truck crane, inline-6 Euro V diesel, CAN-bus SYMC control with ±3% load-moment limiter. Combines chassis (travel) and superstructure (lifting) maintenance.
Daily Pre-Start Checklist
Complete before every shift and again before the first lift of the day. Allow ~15–20 minutes — this covers both chassis (travel) and crane superstructure (lifting) checks.
Every Shift
1
Engine Oil Level
Dipstick — wipe clean, reinsert and pull again (engine cold or after 5 min idle).
Act if: below MIN — top up with correct grade; milky/foaming oil — stop the engine immediately.
2
Engine Coolant Level
Check the overflow reservoir on the engine side — engine must be cool.
Act if: below MIN — top up coolant mix; brown/dirty coolant — plan a flush.
3
Hydraulic Oil Level
Retract the boom fully, outriggers and jib stowed; check the sight glass on the 686 L tank.
Act if: below visible range — top up; milky/white colour (water) — stop and investigate.
4
Fuel Level
Check the fuel gauge and drain water from the sediment bowl (350 L tank, ≤43 L/100 km road).
Act if: below ¼ tank — refuel before the shift. Never run dry.
5
Tyres — Pressure & Condition
Visually check all wheels (12.00R20-20PR × 12); inspect sidewalls and tread for damage.
Act if: cuts, bulges or low pressure — do not travel or set up outriggers until corrected.
6
Walk-Around Leak Check
Walk a full circle — check the ground beneath the chassis and crane superstructure for fluid.
Act if: any active drip or puddle (fuel, oil, coolant) — find the source and repair before starting.
7
Air Filter Indicator
Check the dashboard/filter-housing indicator; tap and clean the pre-cleaner if working in dust.
Act if: indicator in the red zone — clean or replace the primary element before starting.
8
Battery & Terminals
Check the 2 × 12 V battery terminals are clean, tight and corrosion-free.
Act if: loose/corroded — clean and re-tighten; no charge indication — do not operate, investigate the alternator.
9
Outriggers, Wire Rope & Hook
Inspect outrigger pads/cylinders for leaks; check main/aux wire rope for kinks, broken strands and corrosion; inspect the main hook (610 kg) for cracks.
Act if: damaged rope, bent hook or outrigger cylinder leak — stop; do not rig or lift until inspected.
10
Load Moment Limiter & Safety Devices
Power on and confirm the LMI, height limiters and over-roll-out limiters respond on the display before any lift.
Act if: limiter fault, no display response, or an alarm that will not clear — do not lift; report for inspection.
11
Horn, Lights, Wipers & Backup Alarm
Press the horn; test all lamps, indicators, wipers and the reverse/backup alarm.
Act if: any failure — fix before the shift; backup alarm not working — do not operate.
12
Steering, Brakes & Fasteners
Check steering free play and brake-pedal feel; visually check transmission-shaft bolts, U-bolts, hub bolts and wheel nuts.
Act if: spongy brakes, excess steering play, or loose/missing fasteners — do not travel; rectify first.
13
Grease All Pin Points
Grease gun on boom sections, jib, slewing bearing, outrigger and linkage nipples.
Act if: no old grease purges out — keep applying until it exits. Minimum every 8–10 operating hours.
Note: the STC600S is both a road vehicle and a lifting machine — complete the chassis checks (tyres, brakes, steering, fasteners) and the crane checks (wire rope, hook, outriggers, load-moment limiter) before the first lift. Grease all pivot points every 8–10 operating hours.
Service Schedule by Hourmeter
Use the hourmeter reading — do not delay when a service is due. Read cumulatively. CHANGE / REPLACE / INSPECT / GREASE / CHECK / CLEAN.
Daily — every shift. Carried forward into every higher interval.
Engine, Fuel & Cooling
Oil, coolant & fuel levels
Check dipstick, reservoir & gauge; drain water separator
CHECK
Air filter indicator & radiator
Check restriction indicator; visual radiator fins
CHECK
Hydraulics & Wire Rope
Hydraulic oil level
Sight glass with boom retracted (686 L tank)
CHECK
Hoses, cylinders & wire rope
Walk-around for leaks; visual rope for kinks/broken wire
INSPECT
Chassis & Brakes
Tyres & fasteners
Pressure/damage on 12 wheels; visual wheel-nut/U-bolt tightness
CHECK
Brakes & CAN-bus
Test travel/parking/exhaust brakes; confirm no fault codes at start-up
CHECK
Crane & Greasing
LMI, limiters & anemometer
Functional test before lifting; check boom-head sensors
CHECK
All pivot points
Grease boom/jib/slewing bearing/outrigger pins every 8–10 h
GREASE
Weekly — every 50–100 operating hours (plus all daily tasks).
Engine
Engine oil & filter 1
Change oil (grade/capacity per engine OEM manual); replace genuine filter
Change 9-speed gearbox, all drive-axle, slewing & winch gearbox oil
CHANGE
Brakes & battery
Inspect/adjust brakes; test battery & charging
INSPECT
Boom, Rope & Structure 2
Wire rope replacement
Replace main & auxiliary ropes if wear criteria met
REPLACE
Boom NDI & LMI
Non-destructive inspection of boom sections & critical welds; LMI calibration
INSPECT
1 Confirm engine, gearbox and axle oil capacities and grades with a SANY-authorised service centre. 2 Confirm wire-rope, structural and LMI-calibration intervals before service. Hydraulic-tank capacity is 686 L and fuel-tank capacity is 350 L. Confirm exact quantities and intervals before ordering parts.
Warning Alerts & Immediate Actions
Monitor the CAN-bus operation display and LMI for alerts. RED = stop the engine or crane motion immediately; AMBER = act before continuing.
Red — Stop immediatelyAmber — Act before continuing
RED
Engine Oil Pressure
Oil pressure dropped — the engine is running without lubrication.
Immediate action: STOP THE ENGINE IMMEDIATELY. Do not wait. Find the cause before restarting.
Risk if ignored: complete, irreversible engine seizure — contact a SANY dealer.
RED
Engine Overheating
Coolant failing, radiator blocked or fan failure.
Immediate action: stop work. Idle 2 minutes, then shut down. Check coolant and radiator.
Risk if ignored: warped cylinder head, blown head gasket, seized engine.
RED
Load Moment Limiter Overload
Load/moment has reached the rated limit — the system alarms and cuts off the dangerous action.
Immediate action: STOP the lifting motion. Lower or slew back within the safe radius before continuing. Do not override.
Risk if ignored: tip-over, boom structural failure, dropped load — risk to life.
RED
Tip-Over Early-Warning
Stability margin is approaching the tipping threshold.
Immediate action: stop all crane motion. Reduce radius or load before any further movement.
Risk if ignored: crane overturn — catastrophic loss and severe injury risk.
RED
Battery / No Charge
Alternator not charging — the electrical system is failing.
Immediate action: check the drive belt and alternator terminal connections immediately.
Risk if ignored: machine won't restart; CAN-bus control may become unreliable.
AMBER
Hydraulic Oil Temperature
Hydraulic oil overheating — system overloaded or oil cooler blocked.
Immediate action: stop work. Idle 10–15 minutes with no hydraulic movement to cool the system.
Risk if ignored: pump seal failure, cylinder and control-valve damage.
AMBER
Air Filter Restriction
Air filter blocked — the engine is not getting enough clean air.
Immediate action: stop work. Remove and inspect the outer air filter. Clean or replace.
Risk if ignored: power loss, black smoke, overheating, injector and turbo damage.
AMBER
Hydraulic Leak / Pressure Drop
Pressure drop — hose, joint or seal failure.
Immediate action: stop all work. Do not operate. Locate and repair the leak before restarting.
Risk if ignored: total hydraulic failure, uncontrolled boom/outrigger movement, fire risk.
AMBER
High Wind Speed (Anemometer)
Boom-head anemometer reports wind approaching the safe lifting limit.
Immediate action: stop lifting. Lower the boom and secure the load. Do not resume until the wind drops.
Risk if ignored: loss of load control, boom whip, tip-over in gusts.
AMBER
Low Fuel
Fuel near empty — the 350 L tank is approaching reserve.
Immediate action: refuel as soon as possible. Do not run dry.
Risk if ignored: running dry pulls tank sediment into the injectors — expensive repair.
AMBER
Over-Roll-Out / Height Limiter
Main or auxiliary wire rope is approaching its roll-out or height limit.
Immediate action: stop the hoist/boom motion. Reverse direction slowly to clear the limit switch.
Risk if ignored: wire-rope roll-out, boom-tip damage, dropped load.
Critical: if the RED Load Moment Limiter Overload or Engine Oil Pressure warning activates, stop the relevant motion or the engine immediately — do not wait. Any machine with a red overload or oil-pressure event must be inspected by a SANY-authorised technician before returning to lifting duty.
Everything you need to know about the SANY STC600S Truck Crane
The SANY STC600S has a maximum rated lifting capacity of 60 Tonnes with a load moment of 2,009 kN·m at base boom, making it suitable for heavy construction, bridge lifting, and large-scale industrial operations.
The SANY STC600S features a 5-section U-shape telescopic boom with full extension to 43.5 m. With the optional foldable jib (9.2 m or 16 m), total combined reach extends to 59.5 m for high-reach construction and industrial lifts.
The SANY STC600S is powered by a 247 kW @ 1,900 rpm turbocharged diesel engine with 1,425 N·m torque. It uses a SANY SYMC CAN-bus full-digital control system with load moment limiter (±3% accuracy) and load-sensitive variable displacement hydraulic pump for energy-efficient operation.
The SANY STC600S reaches a maximum road speed of 85 km/h with a 9-speed manual gearbox on an 8×4 chassis. Its minimum turning radius of 11.5 m allows easy maneuvering on construction sites and urban roads.
The SANY STC600S has H-type 4-point fully hydraulic outriggers with max span of 6.0 m × 7.2 m. The counterweight system includes a 4.6T fixed counterweight plus optional 3.0T flexible counterweight, providing enhanced stability for the full 60T lifting capacity.
